SmartElex Wireless Remote Control with NRF Transceiver and Motor Driver

We know that hobbyists are willing to build the wireless remote control robotic vehicle. Mostly hobby people faced the complexity, Operating Range, Accuracy, signal switching issues & mainly those are expensive. To solve these, we are introducing SmartElex Wireless Remote control & Receiver integrated with motor driver & NRF24L01 RF module. NRF24L01 features a reverse polarized SMA connector for the maximum RF range. This module comes with the 2.4G antenna (2DB), with a 250Kbps transmission rate on open-air it can reach the 800-1K meters communication distance.
We made a combo of the following essential product

Features:

Wireless NRF24 Features:

• 2.4GHz NRF24L01+PA+LNA SMA Wireless Transceiver
• 1. ISM frequency band: 2.4GHz.
• 2. Operating Range: 1km.
• 3. Operating speed:
• • 2MB rate (Open area):520m.
• • 1MB rate (Open area):750m.
• • 250Kb rate (Open area): 1100m.
• 4. Antenna Gain (peak): 2Dbi.

Receiver module features:

• 1. Operating voltage: 5 V to 12 V.
• 2. Output current: 1.2 A continuous (2 A peak) per motor.
• 3. Motor outputs can be paralleled to deliver 2.4 A continuous (4 A peak) to a single motor.
• 4. Under-voltage lockout and protection against over-current and over-temperature.
• 5. Reverse-voltage protection circuit.

Package Includes:

• 1 x SmartElex Transmitter Module.
• 1 x SmartElex Receiver module with integrated Motor Driver.
• 1 x 9v Non-Rechargeable (Alkaline) Battery.
• 2 x SMA Antenna (Male)
